High Speed Semi Automatic Stretch Blow Molding Machine 16KW PET Bottle
Premium Products
High Speed Semi Automatic Stretch Blow Molding Machine 16KW PET Bottle
1
2
Brand Name :Eceng
Model Number :YC-2L-2
Certification :CE,ISO
Place of Origin :Jiangsu, China
MOQ :1set
Payment Terms :L/C, T/T, Western Union
Supply Ability :20 Set/Sets per Month
Delivery Time :10days
Packaging Details :Wooden package
Plastic Processed :PET
Condition :New
Application :bottle
Blow Moulding Type :Stretch Blow Moulding
Hollow part volume :2l
Automation :Semi-automatic
Warranty :1 Year, one year
Key Selling Points :Easy to Operate
Warranty of core components :1 Year
Color :orange
Name :semi automatic pet bottle blowing machine
Power(W) :16KW
Contact Now
Product Description
Universal semiautomatic blowing machine for PET bottles 0.1-2l with output 1500-2000BPH. Universal and flexible, ideal solution with low investment cost.
1.Quick-change for another bottle Format 2.Handy and simple operation mode 3.setup on LCD display 4.15 and 25 bars main blow pressure 5.IR lamps for deep preforms heating 6.Orginal pneumatic scheme 7.Start-up and maintenance-friendly 8.Multiple bottle formats & volumes 9.Space-saving overall dimensions
Main machine (blower + oven)
Item
YC-5L-1
Product Spec
Max. product volume(L/cav)
5L
Max. preform neck size(mm)
100
Max. product diameter(mm)
180
Max. product height (mm)
300
Cavities
4
Blow molding part
Die force (KN)
100
Die stroke (mm)
270
Max. mould size(mm)
390*345
Mould thickness
Adjustable
Mould spacing(mm)
Adjustable
Max. pulling stroke(mm)
400
Operation pressure(Mpa)
0.8-1.0
Operation air pressure consumption
(1tr/min)
200
Blow pressure(Mpa)
1.2-2.8
Blow air pressure consumption (1tr/min)
300
Output(pcs/h)
2600-2800(500ml bottle)
Machine size(LxWxH)(m)
1.46*0.58*1.8
Machine weight(KG)
650
Oven
Temperature grade(rate)
8
Heating time(S)
90-200
Voltage(V)
220 or as your request
Frequency(HZ)
50/60
Total power(KW)
16
Oven Size (LxWxH)
1.35*0.55*1.15
Oven weight (KG)
300
YC series semi-automatic bottle blowing machine is controlled bymicrocomputer,control the technical parameters more accurately.PET bottle blowing machine is simple and safe to operate.It only requires one person and does not require special training.YC series PET blow molding machine is suitable for blow molding of plastic packaging bottles such as carbonated beverage bottles, mineral water bottles, hot filling bottles and cosmetic bottles. It is suitable for the production of small beverage companies and daily chemical product companies.
Adopt infrared lamp heating, strong penetration, preform rotation heating, track revolution, heating evenly, fast and reliable; heating lamp,reflector width and height can be adjusted to suit preform heating of different structure,with automatic temperature-removal device to ensure the constant temperature of oven.
Specially designed high rigidity composite mold structure, wide applicability, suitable for various types of mold thickness, easy to adjust and save energy, less air demand, precision polished spindle, equipped with photoelectric sensor, low noise,rapid response, long working hours , stable performance,ensure stable operation.
YC linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type.
Q:Your company is a trading company or a direct factory?
A:We are a direct factory which locates in Zhangjiagang city.
Q:All of your products are made by yourself or compacted via purchasing the others?
A:We have independent technical team who focus on making machines,all the products are made by our technical team.
Q:What is the ability of your factory?
A:About 80 lines per year.
Q:Do you have any other services about your products?
A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.
Q:How do you make the quotation for clients?
A:The price depends on quality and performance but the clients should be satisfied first.
